Product Overview: PIC32MX795F512L-80V/PT

The PIC32MX795F512L-80V/PT is a high-performance 32-bit microcontroller (MCU) from Microchip Technology, designed to deliver the computational power and data bandwidth necessary for embedded control and connectivity applications. This MCU is a member of the PIC32MX family, which is renowned for its high-speed instruction execution, ideal for an array of applications ranging from industrial control systems to sophisticated multimedia devices.

Key Features

• Core: The MCU is built around a powerful MIPS M4K Core, running at up to 80 MHz, providing a perfect balance between computational power and energy efficiency.
• Memory: It boasts 512 KB of Flash memory and 128 KB of RAM, allowing ample space for application code and data storage.
• Digital I/O: Equipped with an extensive set of peripherals, it includes digital I/O pins that support various communication protocols such as UART, SPI, I2C, CAN, and USB.
• Analog Features: The device also includes several 10-bit Analog-to-Digital Converters (ADCs), providing the ability to interface with analog sensors and devices.
• Connectivity: With its integrated Ethernet MAC and PHY, it is ready for networked applications, making it ideal for Internet of Things (IoT) devices.
• Timers and PWM: Advanced timer modules and PWM outputs enable precise control over timing-related tasks, such as motor control and power management.
• Package: The MCU comes in a 100-pin TQFP package, which is suitable for surface-mount technology and compact PCB designs.

Applications

The PIC32MX795F512L-80V/PT is versatile enough to fit a wide range of applications, including:

• Industrial Automation
• Home Automation Systems
• Advanced Audio and Voice Processing
• Networking and Communication Systems
• Automotive Accessories
• Medical Devices

Development Support

Microchip provides extensive support for development with the PIC32MX795F512L-80V/PT, including software libraries, development boards, and the MPLAB X Integrated Development Environment (IDE). This ecosystem of tools enables rapid development and debugging of applications, reducing time to market.

With its robust set of features and capabilities, the PIC32MX795F512L-80V/PT MCU from Microchip Technology stands out as a top choice for engineers and designers looking to push the boundaries of what's possible in embedded systems design.
