Product Overview: TC1015-4.0VCT713

The TC1015-4.0VCT713 is a high-precision, low-dropout voltage regulator designed and manufactured by Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions. This regulator is specifically engineered to maintain a stable output voltage of 4.0 volts, making it an ideal choice for sensitive electronic components that require consistent power to operate effectively.

Key Features:

• High Accuracy: The TC1015-4.0VCT713 boasts an impressive output voltage accuracy, ensuring reliable performance for critical applications.
• Low Dropout: With its low dropout voltage, this regulator operates efficiently even when the input voltage is very close to the output voltage, minimizing power loss and heat generation.
• Low Power Consumption: Designed for energy-sensitive systems, it features a quiescent current of just 50 µA, which helps to extend battery life in portable devices.
• Output Current: Capable of delivering up to 150 mA, this regulator can support a range of low-power applications.
• Thermal Protection: The device includes an over-temperature shutdown feature that protects it from damage due to excessive heat.
• Short-Circuit Protection: It is equipped with short-circuit protection, ensuring safety and reliability under abnormal conditions.

Applications:

The TC1015-4.0VCT713 is versatile and can be used in various applications, including:

• Battery-powered devices
• Portable electronics
• Microcontroller power supplies
• Reference voltage sources
• Consumer electronics

Package and Availability:

This voltage regulator is available in a compact SOT-23-5 package, which is suitable for space-constrained applications. Its small footprint allows for integration into a wide range of electronic devices without significantly impacting the overall design size.

With its combination of high accuracy, low power consumption, and robust protection features, the TC1015-4.0VCT713 from Microchip Technology is a reliable choice for designers looking to enhance the performance and efficiency of their electronic systems.
