206640-0001 Molex, LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

206640-0001

Part No 206640-0001
Manufacturer Molex, LLC
Catalog RF/IF and RFID
Description GNSS Active Patch Antenna with L
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Navigation
Frequency Group UHF (1GHz ~ 2GHz)
Frequency (Center/Band) 1.561GHz, 1.575GHz, 1.602GHz
Frequency Range 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.597GHz ~ 1.607GHz
Antenna Type Ceramic Patch
Number of Bands 3
VSWR 3
Return Loss -8dB
Gain 4.5dBi, 4.5dBi, 4.5dBi
Features Cable - 60mm, LNA
Termination U.FL (UMCC), I-PEX MHF1
Mounting Type Adhesive
Height (Max) 0.256" (6.50mm)
Applications Beidou, Galileo, GLONASS, GNSS, GPS
Ultra Librarian 3D Model Ultra Librarian 206640-0001 CAD Model
