Same model may have multiple batches, images only for reference.
22-28-4033 Real Image
Same model may have multiple batches, images only for reference.

22-28-4033

Part No 22-28-4033
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description KK 254 Breakaway Header Vertical 3 Circuits 0.38um Gold Selective Plating Mating Pin 6.09mm
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 6.096 mm
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 4 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 8.38 mm
Housing Color Black
Housing Material Thermoplastic
Lead Free Yes
Lead Pitch 2.54 mm
Length 7.62 mm
Maximum Operating Temperature 75 °C
Max Voltage Rating (DC) 250.25 kV
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 3
Number of Contacts 3
Number of Positions 3
Number of Rows 1
Orientation Vertical
Packaging Bulk
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1026787-22-28-4033
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 22-28-4033 CAD Model

Description

The Molex LLC 1026787-22-28-4033 is a male pin connector with a pitch of 2.54 mm and a number of positions of 3.

  • Pitch: 2.54 mm
  • Positions: 3
  • Voltage Rating: 250 V
  • Current Rating: 4 A
  • Contact Material: Brass
  • Termination: Solder
  • Length: 7.62 mm
  • Height: 8.38 mm
  • Housing Material: Thermoplastic
  • Housing Color: Black
  • Contact Plating: Gold
  • Contact Resistance: 20 mΩ
  • Supply and Demand: Shortage
  • Packaging: Bulk
