Part No 47659-1001
Manufacturer Molex, LLC
Catalog Barrel - Audio Connectors
Description Conn Rectangular F 15 POS Solder ST SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Plating Gold
Country of Origin CN
Current Rating 500 mA
Gender Female
Halogen Free Low Halogen
Housing Material Thermoplastic
Length 15 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (DC) 40 V
Min Operating Temperature -20 °C
Mount Surface Mount
Number of Circuits 19
Number of Contacts 19
Number of Pins 19
Number of Ports 1
Number of Positions 19
Number of Rows 2
Number of Terminals 19
Orientation Vertical
Pitch 500 µm
Plating Gold, Tin
Radiation Hardening No
RoHS Compliant
Termination Solder
Voltage Rating (DC) 40 V
Win Source Part Number 997087-47659-1001
Categories Barrel - Audio Connectors
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 47659-1001 CAD Model

Description

This female connector from Molex, LLC is a high-quality electronic component that is perfect for use in a variety of applications.

  • Positions: 19
  • Pitch: 500 µm
  • Current Rating: 500 mA
  • Housing Material: Thermoplastic
  • Contact Plating: Gold
  • RoHS Compliant: Yes
  • Maximum Operating Temperature: 85 °C
  • Mounting: Surface mountable
