The Molex 500913-0602 is a Micro-Lock Plus Wire-to-Board Connector. This connector system provides a secure and reliable electrical connection in a compact design. It's designed for applications where space is limited and a robust connection is required, offering features like a positive lock and high mating retention forces. The connector mates with crimp terminals attached to wires.

Applications:

• Consumer electronics
• Industrial automation
• Robotics
• Medical equipment
• Lighting systems
• Automotive electronics
• Data communication equipment
• Power supplies
• HVAC systems

Features:

• Micro-Lock Plus design for secure mating
• 6 circuits/positions
• Single Row
• 1.25mm pitch
• Surface mount termination
• Positive locking mechanism
• High mating retention force
• Compact size
• RoHS Compliant

Benefits:

• Ensured reliable electrical connection due to secure latching
• Space saving in compact devices due to small footprint
• Reduced risk of accidental disconnection due to positive lock and high retention force
• Suitable for reflow soldering processes
• Durable performance over a wide temperature range
• Simplified manufacturing process through automated assembly compatibility

Additional Details:

The 500913-0602 is a surface mount connector with a 1.25mm pitch. The connector uses a positive locking feature to prevent accidental unmating. The high mating retention force ensures a secure connection even in demanding environments. The housing material is typically a UL 94V-0 rated plastic, providing flammability resistance. The terminals are typically tin or gold plated for improved conductivity and corrosion resistance. This connector is often used in applications where a compact, reliable, and secure wire-to-board connection is needed. The operating temperature range is typically -40°C to +105°C. The mating connector typically involves crimping terminals onto wires which then snap into the connector housing and mate with the header soldered to the PCB.
