504187-2670 Real Image
Same model may have multiple batches, images only for reference.

504187-2670

Part No 504187-2670
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Micro-Lock 1.25mm Pitch Dual-Row Vertical Header, Beige, 26 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Plating Tin
Country of Origin MY
Fastening Type Latch
Glow Wire Compliant Non-compliant
Mount Surface Mount
Number of Circuits 26
Number of Positions 26
Number of Rows 2
Orientation Vertical
Pitch 1.2446 mm
Plating Nickel
RoHS Compliant
Termination Solder
Win Source Part Number 1024281-504187-2670
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 504187-2670 CAD Model

Description

The Molex 1024281-504187-2670 is a high-quality male pin connector that is perfect for use in circular connectors.

  • Product Name: Molex 1024281-504187-2670
  • Gender: Male
  • Positions: 26
  • Pitch: 1.2446 mm
  • Color: Natural
  • Material: Nickel-plated tin
  • Fastening Type: Latch
  • Mount: Surface mount
  • RoHS Compliant: Yes
  • Popularity: Low
  • HTSUS: 8536.90.4000
  • Alternative Part Numbers: 504187-1870, 504187-2870, 504187-3870, 5-175643-0, 3-175635-6, 4-175638-005041872670, 5041872670
  • Application: Circular connectors - housings
