52465-1471 Real Image
Same model may have multiple batches, images only for reference.

52465-1471

Part No 52465-1471
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Board to Board RCP 14 POS 0.8mm Solder ST SMD SlimStack™ Automotive T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Bronze
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin KR
Current Rating 500 mA
Depth 3.2 mm
Gender Receptacle
Glow Wire Compliant Non-compliant
Housing Color Natural
Housing Material Thermoplastic
Length 7.2 mm
Max Operating Temperature 105 °C
Min Operating Temperature -20 °C
Mount Surface Mount
Number of Circuits 14
Number of Contacts 14
Number of Positions 14
Number of Rows 2
Orientation Vertical
Packaging Tape & Reel
Pitch 800 µm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating 50 V
Win Source Part Number 1192143-52465-1471
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 52465-1471 CAD Model

Description

The Molex 1192143-52465-1471 is a 14-position receptacle with 2 rows, designed for surface mount applications.

  • Number of Positions: 14
  • Number of Rows: 2
  • Pitch: 800 µm
  • Contact Material: bronze
  • Contact Plating: tin
  • Voltage Rating: 50 V
  • Current Rating: 500 mA
  • Contact Resistance: 20 mΩ
  • Housing Material: thermoplastic
  • Color: natural
  • RoHS Compliant: yes
  • Maximum Operating Temperature: 105 °C
  • Applications: circular connector housings
  • Supply and Demand Status: limited
