The Molex 55339-1208 is a Micro-Fit 3.0 connector header, designed for secure and reliable board-to-wire connections. It features a compact design and positive locking mechanism, making it suitable for various applications where space is limited and secure connections are essential.

Applications

• Consumer electronics: Interconnections in appliances, TVs, and gaming consoles.
• Automotive industry: Control modules and wiring harnesses in vehicles.
• Industrial equipment: Signal and power connections in machinery and control systems.
• Telecommunications: Board-to-wire connections in communication devices.
• Medical devices: Interconnects in patient monitoring and diagnostic equipment.

Features

• Micro-Fit 3.0 design for high density and compact size.
• Positive locking mechanism for secure mating.
• Durable housing material for long-lasting performance.
• Through-hole mounting for secure attachment to the PCB.
• Available in various circuit sizes to meet specific application requirements.

Benefits

• Provides a reliable and secure electrical connection.
• Reduces the risk of accidental disconnections.
• Simplifies board-to-wire assembly processes.
• Enhances the overall quality and reliability of the final product.
• Offers a cost-effective solution for high-density interconnects.

Additional Details

The 55339-1208 is typically used with Micro-Fit 3.0 series crimp terminals and housings. It features a 3.0mm pitch. The housing material is often made of UL 94V-0 rated material, ensuring flame retardancy. The current and voltage ratings depend on the specific terminals and wires used. It is critical to use the correct mating connector and crimping tools to ensure proper termination and prevent damage to the connector or PCB. The number of circuits is 12.
