70553-0009

Name: 70553-0009
Brand: Molex, LLC
SKU: 999738
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	70553-0009
Manufacturer	Molex, LLC
Catalog	Circular Connectors - Housings
Description	Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole Automotive
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Color	Black
Contact Material	Brass
Contact Plating	Gold
Contact Resistance	30 mΩ
Country of Origin	US
Current Rating	3 A
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Male
Glow Wire Compliant	Non-compliant
Height	5.08 mm
Housing Color	Black
Housing Material	Thermoplastic
Insulation Resistance	1 GΩ
Lead Free	Yes
Lead Pitch	2.54 mm
Length	27.9 mm
Material	Brass
Maximum Operating Temperature	105 °C
Min Operating Temperature	-40 °C
Mount	Through Hole
Number of Circuits	10
Number of Contacts	10
Number of Positions	10
Number of Rows	1
Orientation	Right Angle
Pitch	2.54 mm
Plating	Tin
Radiation Hardening	No
REACH SVHC	Unknown
RoHS	Compliant
Termination	Through Hole
Voltage Rating	250 V
Voltage Rating (DC)	250 V
Width	13.6 mm
Win Source Part Number	999738-70553-0009
Categories	Circular Connectors - Housings
Manufacturer	Molex, LLC
Popularity	Low
Supply and Demand Status	Shortage
Ultra Librarian 3D Model	Ultra Librarian 70553-0009 CAD Model

Alternative Products

Description

This is a 10-position male circular connector housing from Molex, LLC that is designed for through-hole termination.

Positions: 10
Termination: through-hole
Contact Material: brass
Contact Plating: gold-plated
Housing Material: thermoplastic
Pitch: 2.54 mm
Voltage Rating: 250 V
Current Rating: 3 A
Contact Resistance: 30 mΩ
Orientation: right-angle
Height: 5.08 mm
Width: 13.6 mm
Length: 27.9 mm
Housing Color: black
Contact Plating: gold
RoHS Compliant: Yes
Maximum Operating Temperature: 105 °C
Insulation Resistance: 1 GΩ
Category: circular connectors - housings
Supply and Demand Status: shortage
