MP3302DJ-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP3302DJ-LF-Z Real Image
Same model may have multiple batches, images only for reference.
MP3302DJ-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP3302DJ-LF-Z Real Image
MP3302DJ-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP3302DJ-LF-Z Real Image
Same model may have multiple batches, images only for reference.

MP3302DJ-LF-Z

Part No MP3302DJ-LF-Z
Manufacturer Monolithic Power Systems Inc.
Catalog PMIC - LED Drivers
Description IC LED DRV RGLTR SGL WR TSOT23-5
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Package Tape & Reel (TR);Cut Tape (CT);
Product Status Active
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Voltage - Supply (Min) 2.5V
Voltage - Supply (Max) 6V
Voltage - Output 36V
Current - Output / Channel 1.33A (Switch)
Frequency 1.3MHz
Dimming Single-Wire
Applications Backlight
Operating Temperature -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-23-5 Thin, TSOT-23-5
Supplier Device Package TSOT-23-5
Ultra Librarian 3D Model Ultra Librarian MP3302DJ-LF-Z CAD Model

Description

The Monolithic Power Systems Inc. MP3302DJ-LF-Z is a DC-DC regulator designed for backlight applications.

  • Type: Step-up (boost) converter
  • Frequency: 1.3MHz
  • Switch: Internal
  • Output: Single
  • Dimming: Single-wire
  • Output Voltage: 36V
  • Package: TSOT-23-5
  • Maximum Supply Voltage: 6V
  • Input Voltage (min): 2.5V
  • Channel Current: Up to 1.33A
  • Status: Active
  • Reel Package: 3k pcs per package
