WRA1215S-1WR2 MORNSUN Science& Technology Ltd.
Same model may have multiple batches, images only for reference.

WRA1215S-1WR2

Part No WRA1215S-1WR2
Catalog Power Supplies Board Mount DCDC Converters
Description ISOLATED MODULE DC DC CONVERTER
Sample
Rohs State rohs
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr MORNSUN Science& Technology Ltd.
Series WRA_S-1WR2 (1W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 9V
Voltage - Input (Max) 18V
Voltage - Output 1 15V
Voltage - Output 2 -15V
Current - Output (Max) 33mA, 33mA
Power (Watts) 990 mW
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off
Temperature Range - Operating -40°C ~ 85°C
Efficiency 78%
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Approval Agency CE, EN, UKCA
Standard Number 62368-1
Standard Package 22 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 697816-WRA1215S-1WR2
Ultra Librarian 3D Model Ultra Librarian WRA1215S-1WR2 CAD Model

Description

The MORNSUN WRA1215S-1WR2 is a 1W isolated module power supply from MORNSUN Science & Technology Ltd.

  • Application: Designed for use in power supplies - board mount - DC DC converters
  • Size: 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
  • Voltage Isolation: 1.5 kV
  • Outputs: Two outputs with a maximum current of 33mA each
  • Input Voltage Range: 9V to 18V
  • Output Voltage: 15V and -15V
  • Efficiency: 78%
  • Package: 8-SIP module, 7 leads package
  • Applications: Suitable for ITE (Commercial) applications
  • Approvals: CE, EN, and UKCA
