Same model may have multiple batches, images only for reference.

HPR116C

Name: HPR116C
Brand: Murata Power Solutions Inc.
SKU: 1033002
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	HPR116C
Manufacturer	Murata Power Solutions Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-12V 1W / Isolated Module DC DC Converter 2 Output 12V -12V 30mA, 30mA 13.5V - 16.5V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Murata Power Solutions Inc.
Series	HPR1xxC (0.75W)
Package	Tube
Product Status	Not For New Designs
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	13.5V
Voltage - Input (Max)	16.5V
Voltage - Output 1	12V
Voltage - Output 2	-12V
Current - Output (Max)	30mA, 30mA
Power (Watts)	1 W
Voltage - Isolation	750 V
Applications	ITE (Commercial)
Temperature Range - Operating	-40°C ~ 100°C
Efficiency	76%
Mounting Type	Through Hole
Package / Case	7-SIP Module, 5 Leads
Dimension	0.77" L x 0.24" W x 0.40" H (19.6mm x 6.1mm x 10.2mm)
Base Product Number	HPR1
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Standard Package	48
Win Source Part Number	1033002-HPR116C
Ultra Librarian 3D Model	Ultra Librarian HPR116C CAD Model

Alternative Products

Description

The HPR116C is a 1W isolated DC-DC converter module from Murata Power Solutions.

Output Power: 1W
Type: isolated DC-DC converter
Input Voltage Range: 13.5V to 16.5V
Output Voltages: 12V and -12V
Output Current (Max): 30mA per output
Application: ITE (Commercial)
Isolation Voltage: 750V
Package: 7-SIP module with 5 leads
Operating Temperature: -40°C to 100°C
Series: HPR1xxC
Efficiency: 76%
