PMPB20XPE,115

Part No PMPB20XPE,115
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 7.2A SOT1220
Datasheet
PMPB20XPE,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 7.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 900mV @ 250μA
Max Gate Charge 45nC @ 4.5V
Max Input Capacitance 294pF @ 10V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 1.7W (Ta), 12.5W (Tc)
Maximum Rds On at Id,Vgs 23.5 mOhm @ 7.2A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-DFN2020MD (2x2)
Dimension 6-UDFN Exposed Pad
Win Source Part Number 1089734-PMPB20XPE,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMPB20XPE,115 CAD Model

Description

The Nexperia PMPB20XPE,115 is a P-Channel MOSFET with a drain-source breakdown voltage of 20V.

  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 7.2A @ 25°C
  • Maximum Gate Charge: 45nC @ 4.5V
  • Maximum Rds On: 23.5 mOhm @ 7.2A, 4.5V
  • Maximum Input Capacitance: 294pF @ 10V
  • Maximum Gate-Source Voltage: ±12V
  • Gate-Source Threshold Voltage: 900mV @ 250μA
  • Package: 6-DFN2020MD (2x2)
  • Dimension: 6-UDFN Exposed Pad
  • Category: Discrete Semiconductor Products
  • Status: active
  • Temperature Range: -55°C to 150°C (TJ)
  • Supply and Demand Status: sufficient
