Product Overview: 74HCT08D,653

The 74HCT08D,653 is a high-speed Si-gate CMOS device that is part of the 74HCT family of integrated circuits. Manufactured by NXP Semiconductors, this product is designed to provide logic-level conversions while interfacing TTL and CMOS circuits at high speeds. The 74HCT08D,653 is a quad 2-input AND gate that delivers robust performance with the capability to operate in a wide range of industrial and commercial applications.

Key Features

• Logic Type: Quad 2-input AND gate
• Package: SO14 plastic small outline package; 14 leads; body width 3.9 mm
• Supply Voltage Range: 4.5V to 5.5V
• High-Speed Performance: tpd of 8 ns (typ) at VCC = 5V
• Low Power Consumption: ICC of 1 μA (max) at TA = 25°C
• Output Capability: Standard
• Input Level: TTL level
• ESD Protection: HBM JESD22-A114E exceeds 2000V, MM JESD22-A115-A exceeds 200V
• Latch-Up Performance: JESD78 Class II exceeds 100 mA

Applications

The 74HCT08D,653 is suited for a variety of applications where logical AND functions are required. It is commonly used in:

• Logic gates circuits
• Embedded systems
• Control systems
• Signal processing
• Computers and computer peripherals
• Networking equipment

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The 74HCT08D,653 has been rigorously tested to meet industry standards for quality and reliability, ensuring stable and consistent performance in your electronic designs.

Environmental Compliance

The product is compliant with the RoHS Directive 2011/65/EU, reflecting NXP's dedication to environmental sustainability. By choosing the 74HCT08D,653, customers can be confident they are selecting a product that minimizes environmental impact while delivering the functionality required for their applications.
