Products specifications

Categories Discrete Semiconductor Products
Manufacturer NXP
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance @ Vr, F 2pF @ 28V, 1MHz
Capacitance Ratio 8.3
Capacitance Ratio Condition C1/C28
Voltage - Peak Reverse (Max) 30V
Diode Type Single
Temperature Range - Operating -55°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package TO-236AB (SOT23)
Win Source Part Number 094640-BBY31
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name BBY31
Introduction Date November 01, 1993
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian BBY31 CAD Model

Description

The BBY31 from NXP Semiconductors is a high-performance variable capacitance diode, also known as a varicap or varactor diode. This diode is designed to provide excellent tuning and filtering capabilities in a wide range of electronic applications. Its primary function is to allow the capacitance across the diode to be varied by changing the voltage applied to its terminals, making it an ideal component for use in tunable circuits, such as radio frequency (RF) oscillators and filters.

Key Features

  • High-Quality Silicon Technology: The BBY31 is manufactured using NXP's advanced silicon technology, which ensures high reliability and performance.
  • Wide Capacitance Range: This varicap offers a wide tuning range of capacitance, making it suitable for a variety of tuning applications.
  • Low Series Resistance: The low series resistance of the BBY31 ensures minimal signal loss, which is critical for maintaining signal integrity in RF applications.
  • Excellent Linearity: The diode's capacitance variation with voltage is highly linear, which simplifies the design of voltage-controlled oscillators (VCOs) and other tuned circuits.

Applications

The BBY31 is a versatile component that can be used in numerous applications. It is particularly well-suited for:

  • RF tuning and filtering in television and radio receivers
  • Voltage-controlled oscillators in phase-locked loops (PLLs)
  • Frequency modulators and demodulators
  • Automatic frequency control (AFC) systems
  • Electronic tuning in satellite receivers

Technical Specifications

Parameter Value Package SOD-323 Capacitance Range 2.1 - 19 pF Reverse Voltage 28 V Series Resistance 0.8 Ohm (max)

For engineers and designers looking for a reliable and flexible solution for their tuning needs, the BBY31 from NXP Semiconductors is an excellent choice. Its robust design and high-quality performance make it a go-to component for a wide array of electronic tuning applications.
