Products specifications

RoHS State Request Verification
Manufacturer NXP
Win Source Part Number 1156606-BYD17D
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BYD17D CAD Model

Description

The BYD17D is a high-performance fast recovery diode designed and manufactured by NXP Semiconductors. This diode is specifically engineered to deliver efficient and reliable performance in a wide range of applications that require fast switching and low power loss. The BYD17D is a suitable choice for modern electronic equipment where high efficiency is a priority.

Key Features

  • Fast Reverse Recovery Time: The BYD17D boasts a quick reverse recovery time which is essential for high-frequency operations and helps minimize energy loss during switching.
  • Low Forward Voltage Drop: This diode offers a low forward voltage drop, contributing to reduced power dissipation and improved system efficiency.
  • High Surge Current Capability: With its robust design, the BYD17D can handle high surge currents, making it ideal for applications that experience transient over-voltage conditions.
  • Stable Switching Characteristics: The diode provides stable switching characteristics over its entire operating temperature range, ensuring consistent performance.
  • Glass Passivated: The device is glass passivated, which offers enhanced reliability and long-term stability by protecting the semiconductor surface from contaminants and environmental factors.

Applications

The BYD17D is versatile and can be used in various applications, including:

  • Switching power supplies
  • High-frequency inverters
  • Freewheeling diodes in converters
  • Energy storage circuits
  • Snubber circuits
  • Protection circuits

Specifications

Key specifications of the BYD17D include:

Parameter Value Repetitive Peak Reverse Voltage (V<sub>RRM) 200 V Average Forward Current (I<sub>F(AV)) 1 A Non-Repetitive Peak Forward Surge Current (I<sub>FSM) 30 A Reverse Recovery Time (t<sub>rr) 50 ns Operating Junction Temperature (T<sub>j) -65 to +175 °C

With its combination of fast recovery time, low power loss, and high surge current capability, the BYD17D from NXP is an excellent choice for designers looking to enhance the efficiency and reliability of their electronic systems.
