The HEF40106BP is a robust, high-performance hex inverting Schmitt trigger IC, designed and manufactured by NXP Semiconductors. This integrated circuit is part of the HEF4000 family, which is well-known for its versatility and reliability in a wide range of electronic applications. The HEF40106BP is particularly suitable for wave shaping, noise filtering, and in applications where slow input transitions are to be sharpened.

Each of the six inverting Schmitt triggers in the HEF40106BP operates independently and is designed to have a hysteresis voltage that ensures clean switching, even with slow input transition rates. This feature makes it an excellent choice for converting noisy inputs into clean digital outputs.

Key Features

• Logic Family: HEF4000
• Logic Type: Inverting Schmitt Trigger
• Number of Circuits: 6
• Supply Voltage Range: 3V to 15V
• Output Current: 4.2mA at 10V
• Package: DIP-14 (Dual In-line Package)
• Temperature Range: -40°C to +125°C

The HEF40106BP operates across a wide supply voltage range from 3V to 15V, which provides flexibility in various power environments. It can deliver a consistent output current of 4.2mA at 10V, making it suitable for driving light loads. The device is available in a standard DIP-14 package, which is easy to handle and integrate into a broad array of PCB designs.

With its wide temperature range of -40°C to +125°C, the HEF40106BP is built to withstand harsh operating conditions, ensuring reliable performance in both industrial and commercial applications. Whether you are designing a timing circuit, performing signal conditioning, or implementing a debounce circuit for switches, the HEF40106BP provides a practical and efficient solution.

NXP's commitment to quality and performance is evident in the HEF40106BP, making it a smart choice for designers looking for a dependable Schmitt trigger solution.
