Products specifications Report Issue?

Reference Date Code 450
Reference case CSP-5
Manufacturer NXP
Manufacturer Homepage www.nxp.com
RoHS State Request Verification
Win Source Part Number 714516-IP4059CX5
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IP4059CX5 CAD Model

Description

Introducing the NXP IP4059CX5 - Your Solution for Advanced ESD Protection

The NXP IP4059CX5 is a cutting-edge ESD protection device designed to safeguard your sensitive electronic circuits from the detrimental effects of electrostatic discharge. This compact and efficient solution is engineered by NXP Semiconductors, a leader in the industry known for their innovative and reliable products. The IP4059CX5 is an essential component for modern electronic designs, offering both robustness and high performance in a single package.

Key Features of the NXP IP4059CX5:

  • High ESD Protection: The device offers exceptional ESD protection, capable of withstanding electrostatic discharges up to ±15 kV contact discharge and ±30 kV air discharge, as per the IEC 61000-4-2 standard. This ensures the longevity and reliability of your electronics in the face of static events.
  • Low Clamping Voltage: With a low clamping voltage, the IP4059CX5 minimizes the stress on protected components during an ESD event, thereby preventing damage and ensuring the continued performance of your device.
  • Low Capacitance: The device features very low capacitance, which is crucial for maintaining signal integrity in high-speed data lines without compromising on protection.
  • Multi-Channel Integration: It integrates multiple protection channels in a single package, providing a compact solution for protecting several lines at once, which is ideal for space-constrained applications.
  • Wide Operating Voltage Range: The IP4059CX5 is designed to operate over a wide voltage range, making it suitable for various applications and ensuring versatility in design.

Whether you're designing smartphones, portable electronics, or any other application that requires reliable ESD protection, the NXP IP4059CX5 is an excellent choice. Its small form factor combined with its powerful protective features makes it an indispensable component in protecting your electronic investments.

Applications:

The versatility of the NXP IP4059CX5 allows it to be used in a wide array of applications, including:

  • USB interfaces
  • HDMI ports
  • DisplayPort interfaces
  • High-speed data lines

Choose the NXP IP4059CX5 for superior ESD protection that meets the demands of today's high-speed, high-performance electronic environments.
