The NXP LPC2364FET100 is a high-performance microcontroller that is part of the LPC2300 family, designed for embedded applications requiring a blend of low power consumption, advanced interrupt capabilities, and diverse communication interfaces. This microcontroller is particularly well-suited for industrial control, medical systems, and automotive applications, where reliability and efficiency are paramount.

Key Features

• Core: The LPC2364FET100 is powered by a 32-bit ARM7TDMI-S CPU core, which operates at frequencies of up to 72 MHz, providing a balance of power and performance for demanding applications.
• Memory: It comes equipped with 128 KB of on-chip flash memory for program storage and 34 KB of SRAM, ensuring ample space for complex software routines and data handling.
• Communication Interfaces: The microcontroller offers a variety of communication options including USB 2.0 Full-Speed device, two CAN channels, three UARTs, SPI, SSP with buffering and variable data length capabilities, and three I2C-bus interfaces.
• Timers and PWM: Multiple general-purpose timers, a PWM unit with support for three-phase motor control, and a Real-Time Clock with optional battery backup provide versatile timing and control options.
• ADC & DAC: An integrated 10-bit Analog-to-Digital Converter (ADC) with multiple channels and a 10-bit Digital-to-Analog Converter (DAC) enable interfacing with analog sensors and actuators.
• Advanced Interrupt Controller: The Vectored Interrupt Controller (VIC) allows for configurable priorities and vector addresses, which improves interrupt handling efficiency.
• Power Management: The microcontroller features an innovative power management unit that supports multiple power modes, including Idle and Power-down modes, to optimize power consumption.
• Package: The LPC2364FET100 is available in a compact 100-pin LQFP package, which is suitable for space-constrained applications while still offering ample I/O options.

Applications

With its robust set of features and interfaces, the LPC2364FET100 is ideal for a wide range of applications, such as embedded control systems, protocol converters, voice recognition, and GPS receivers. Its ability to handle complex tasks while maintaining low power consumption makes it an excellent choice for portable and power-sensitive applications.
