Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Bulk
Status Obsolete
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration High Side (2)
Interface Parallel
Technology Power MOSFET
Applications General Purpose
Output Current 10A
Supply Voltage (V) 8V ~ 28V
Load Voltage (V) 8V ~ 28V
Temperature Range - Operating -40°C ~ 150°C
Mounting Style SMD
Manufacturer Package 20-SOIC (0.433", 11.00mm Width) Exposed Pad
Supplier Device Package 20-HSOP
Family Part Number MC33486
Manufacturer Pack Quantity 30
MSL Level 3 (168 Hours)
Win Source Part Number 1218425-MC33486ADH
Manufacturer Homepage www.freescale.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC33486ADH CAD Model

Description

The NXP MC33486ADH is a high-performance, automotive-grade power management integrated circuit designed to cater to the demanding requirements of vehicular applications. This robust component is engineered to offer exceptional efficiency and reliability, making it an ideal choice for automotive power systems.

Key Features

  • High Current Handling: The MC33486ADH is capable of managing substantial current loads, making it suitable for high-power applications.
  • Thermal Protection: With built-in thermal protection, the device ensures safe operation by preventing overheating, which is crucial for maintaining performance and longevity in automotive environments.
  • Low Quiescent Current: The low quiescent current feature minimizes power consumption when the device is in a standby state, thereby enhancing the overall energy efficiency of the system.
  • Wide Operating Temperature Range: Designed to withstand extreme temperatures, the MC33486ADH operates reliably across a broad temperature range, which is essential for automotive applications that experience varied environmental conditions.
  • Voltage Regulation: It provides stable voltage regulation, ensuring consistent power supply to critical vehicle systems.

Applications

The MC33486ADH is versatile and can be used in various automotive systems, including:

  • Body Control Modules
  • Infotainment Systems
  • Advanced Driver-Assistance Systems (ADAS)
  • Powertrain Control Modules
  • Electronic Control Units (ECUs)

Quality and Reliability

NXP's commitment to quality is evident in the MC33486ADH, with its compliance to automotive industry standards for quality and reliability. The device is AEC-Q100 qualified, ensuring that it meets the stringent requirements of the automotive sector.

Conclusion

The NXP MC33486ADH stands out as a power management solution designed to meet the rigorous demands of the automotive industry. With its high current capability, thermal protection, energy efficiency, and robust operation across wide temperature ranges, this IC is an excellent choice for manufacturers looking to enhance the performance and reliability of their automotive systems.
