Product Overview: MC9S08QE128CFT by NXP
The MC9S08QE128CFT is a high-performance microcontroller unit (MCU) from NXP's renowned S08 family, designed to cater to a wide range of embedded applications. This MCU is built on NXP's HCS08 core, which operates at a maximum frequency of 50 MHz, providing a robust processing platform for complex and time-sensitive tasks.
With 128 KB of flash memory and 8 KB of RAM, this microcontroller offers ample space for application code and data storage, enabling developers to implement sophisticated programs without worrying about memory constraints. The flash memory is also highly reliable, featuring block protection and security options to safeguard your application's intellectual property.
The MC9S08QE128CFT is equipped with a rich set of peripherals, including an 8-channel 12-bit analog-to-digital converter (ADC), which allows for precise analog signal measurement, making it ideal for sensor interfacing and data acquisition applications. Additionally, it boasts two analog comparators with programmable reference voltage, enhancing its capabilities in control systems.
Connectivity is a strong suit for this MCU, as it includes a serial communications interface (SCI), serial peripheral interface (SPI), and an inter-integrated circuit (I2C) bus, providing versatile options for serial communication with other devices and peripherals.
For timing-sensitive applications, the MC9S08QE128CFT features a timer/pulse-width modulator (TPM) module with up to 6 channels, supporting precise timing operations, PWM outputs, and input capture. It also includes a real-time counter and a periodic interrupt timer, further enhancing its timing capabilities.
This MCU is designed with power efficiency in mind, offering several power-saving modes, such as stop and wait modes, which are essential for battery-operated devices. Its low-power design does not compromise performance, ensuring that the applications remain responsive while conserving energy.
The package is a 48-pin QFP (Quad Flat Package), which provides a compact footprint while still allowing for easy integration into a variety of PCB designs. Whether you're developing consumer electronics, industrial control systems, or automotive applications, the MC9S08QE128CFT provides a reliable and versatile solution for your microcontroller needs.
