Products specifications

Manufacturer NXP USA Inc.
Packaging Tray
Core Processor PowerPC e300
Number of Cores/Bus Width 1 Core, 32-Bit
Speed 667MHz
Co-Processors/DSP Security; SEC
RAM Controllers DDR
Graphics Acceleration No
Ethernet 10/100/1000Mbps (2)
USB USB 2.0 + PHY (2)
Voltage - I/O 2.5V, 3.3V
Temperature Range - Operating 0°C ~ 105°C
Security Features Cryptography, Random Number Generator
Manufacturer Package 672-LBGA
Supplier Device Package 672-TBGA (35x35)
Additional Interfaces DUART, I2C, PCI, SPI
Part Number Series MPC8347
Manufacturer Pack Quantity 24
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 808257-MPC8347EVVALFB
Ultra Librarian 3D Model Ultra Librarian MPC8347EVVALFB CAD Model

Description

NXP MPC8347EVVALFB PowerQUICC II Pro Processor

The NXP MPC8347EVVALFB is a highly integrated microprocessor that embodies the cutting-edge PowerQUICC II Pro family, designed to meet the needs of networking and embedded applications. This processor is built on NXP's advanced Power Architecture® technology, offering a perfect blend of performance, power efficiency, and versatility, making it an ideal choice for a wide range of applications such as industrial control, networking equipment, and storage systems.

Key Features:

  • High-Performance Core: At the heart of the MPC8347EVVALFB is a high-speed e300 core that can run up to 667 MHz, delivering robust computational power for complex tasks.
  • Integrated Security: The processor includes an on-chip security engine that supports various encryption and security protocols, ensuring secure data transmission and storage.
  • System Flexibility: With support for multiple I/O options, including dual Gigabit Ethernet, USB 2.0, PCI, and RapidIO interfaces, this processor provides flexible connectivity solutions for a multitude of system configurations.
  • Memory Support: The MPC8347EVVALFB supports DDR and DDR2 SDRAM memory controllers, allowing for fast and efficient data access and storage.
  • Power Efficiency: Designed with power-sensitive applications in mind, the processor features power management capabilities that help reduce overall system power consumption.

Advanced Integration:

The NXP MPC8347EVVALFB processor integrates a wealth of features to reduce system complexity and component count. Its built-in Serial Peripheral Interface (SPI), I2C controller, and DUART (dual universal asynchronous receiver/transmitter) minimize the need for additional external chips, streamlining design and potentially lowering system costs.

Development Support:

Developers can benefit from the comprehensive suite of tools and software support provided by NXP, including reference platforms, debuggers, and documentation, facilitating a smoother and quicker development process.

Applications:

With its robust feature set and flexible interface options, the NXP MPC8347EVVALFB is well-suited for a variety of applications, including but not limited to network routers, switches, storage systems, industrial automation, and telecommunications equipment.

Overall, the NXP MPC8347EVVALFB is a powerful and efficient solution for designers looking to leverage the performance and reliability of Power Architecture technology in their next-generation embedded and networking products.
