Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Reel - TR
Status Active
Type Buffer, ReDriver
Applications I2C
Input 2-Wire Bus
Output 2-Wire Bus
Data Rate (Max) 400kHz
Number of Channels 1
Capacitance - Input 10pF
Supply Voltage - Operating 2.5 V to 15 V
Operating Supply Current 5.2mA
Temperature Range - Operating -40°C to 85°C
Case / Package 8-TSSOP
Win Source Part Number 088859-PCA9600DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name PCA9600
Introduction Date June 02, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian PCA9600DP CAD Model

Description

NXP PCA9600DP I2C-bus Fm+ Extender

The NXP PCA9600DP is a robust I2C-bus Fm+ extender designed to provide exceptional signal integrity and extended range for I2C communications. This innovative component is part of NXP's high-performance interface products, which are engineered to facilitate reliable and efficient inter-chip communication in complex electronic systems.

Key Features

  • Extended I2C Bus Range: The PCA9600DP is capable of extending the I2C bus communication range to an impressive 1 kilometer, allowing for greater flexibility in system design.
  • Increased Bus Load: It supports more than 4000 pF of bus capacitance, enabling a higher number of devices to be connected on the same bus without signal degradation.
  • Fast-mode Plus (Fm+): With its Fm+ compatibility, the device offers data rates up to 1 Mbit/s, which is a significant improvement over standard I2C speeds.
  • Hot-Swap Capability: The PCA9600DP includes a hot-swap feature that prevents glitches on the bus lines when the power supply is applied, ensuring seamless integration into live systems.
  • Differential Signaling: Utilizing differential I2C-bus signals (I2C-bus buffer) minimizes the effects of electromagnetic interference, thus enhancing signal integrity over long cable distances.

Applications

The PCA9600DP is ideal for a wide range of applications that require robust communication over long distances. These include, but are not limited to:

  • Industrial control systems
  • Building automation
  • Automotive networks
  • Telecommunication infrastructure

Product Specifications

The PCA9600DP comes in a small DIP8 package, making it suitable for space-constrained applications. It operates over a wide supply voltage range (2.3V to 5.5V) and is characterized for operation from -40°C to +85°C, ensuring reliability across various environmental conditions.

For designers and engineers looking to enhance their I2C-bus systems with extended range and improved signal integrity, the NXP PCA9600DP offers a sophisticated and practical solution. Its combination of features makes it an indispensable component in the development of advanced communication networks within a multitude of electronic systems.
