PCF8575TS

Part No PCF8575TS
Manufacturer NXP / Nexperia
Description Remote 16-bit I/O expander for I2C-bus
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

RoHS State Request Verification
Manufacturer NXP
Win Source Part Number 1236247-PCF8575TS
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PCF8575TS CAD Model

Description

The NXP PCF8575TS is a robust I/O expander that provides the flexibility of additional I/O ports for microcontrollers with limited GPIOs. This 16-bit I/O expander uses an I²C-bus/SMBus interface, which ensures seamless integration with most microcontrollers available on the market.

Key Features

  • Expansive I/O: With 16 additional I/O ports, the PCF8575TS significantly increases the number of I/O pins at your disposal.
  • I²C Interface: The device supports both 100 kHz (Standard-mode) and 400 kHz (Fast-mode) I²C protocols, making it suitable for a wide range of applications.
  • Interrupt Output: An interrupt output pin alerts the host microcontroller of any input changes, thus reducing the need for continuous polling.
  • Low Standby Current: Energy efficiency is a key consideration, and this I/O expander offers a low standby current, making it ideal for battery-powered applications.
  • Wide Operating Voltage: It operates across a wide voltage range from 2.5V to 5.5V, accommodating various system requirements.

Applications

The versatility of the PCF8575TS makes it an excellent choice for a multitude of applications, including but not limited to:

  • Server motherboards
  • Embedded systems
  • Industrial control
  • Medical equipment
  • Mobile devices

Package and Quality

The PCF8575TS comes in a slim TSSOP24 package, which is suitable for space-constrained applications. NXP's commitment to quality ensures that this I/O expander meets the stringent requirements of industrial and automotive-grade specifications.

Conclusion

In summary, the NXP PCF8575TS is a highly adaptable I/O expander that can help overcome the limitations of microcontroller I/O availability. Its ease of integration, low power consumption, and interrupt feature make it an intelligent choice for designers looking to enhance their systems without significant redesign.
