Product Overview: TDA1558Q/N1,112

The TDA1558Q/N1,112 is an integrated class-B output amplifier encapsulated in a 17-lead DIL-bent-SIL plastic power package. Manufactured by NXP Semiconductors, this high-performance audio amplifier is designed to deliver quality sound and reliable performance in automotive and consumer audio applications.

Key Features

• High Output Power: The TDA1558Q/N1,112 is capable of delivering up to 22 W of continuous average power to 4 Ω BTL (Bridge-Tied Load) loads with low distortion, making it ideal for car radio applications.
• Flexibility: This amplifier can be used in both Bridge-Tied Load (BTL) and Single-Ended (SE) configurations, providing flexibility in application design.
• Thermal Protection: It includes an integrated thermal protection circuit that shuts down the amplifier in case of excessive temperature, thus safeguarding the device from potential damage.
• Short-Circuit Safe to Ground, to VP, and Across the Load: The TDA1558Q/N1,112 is equipped with robust protection features ensuring its safety and longevity even in adverse conditions.
• Low Standby Current: The low standby current feature makes it suitable for battery-operated devices, contributing to energy efficiency and longer battery life.
• Mode Select Switch: This feature allows for Standby and Mute modes, providing additional control over the amplifier's operation.
• No Switch-On or Switch-Off Clicks: The design ensures that there are no audible clicks during power cycling, improving the user experience.
• Electrostatic Discharge (ESD) Protection: The device includes ESD protection on all pins, enhancing its robustness in handling and operation.

Applications

The NXP TDA1558Q/N1,112 is primarily used in automotive audio systems, but its features make it suitable for a variety of other applications that require reliable and high-quality audio amplification. These include home stereo systems, active speakers, and other audio electronics where space and power efficiency are important considerations.

Conclusion

With its combination of power, flexibility, and protection features, the TDA1558Q/N1,112 from NXP Semiconductors stands out as a top choice for designers looking to create compact and robust audio amplification solutions. Its ease of integration and dependable performance under challenging conditions make it a versatile component in the audio electronics landscape.
