HS100 20R J

Part No HS100 20R J
Manufacturer Ohmite
Catalog Chassis Mount Resistors
Description 100 WATTS AL HOUSED 20 OHMS 5%
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Ohmite
Category Resistors Chassis Mount Resistors
Packaging  Box
Part Status Active
Resistance 20 Ohms
Composition Wirewound
Temperature Coefficient ±100ppm/°C
Features Pulse Withstanding
Coating, Housing Type Aluminum
Mounting Feature Flanges
Size / Dimension 2.567" L x 1.870" W (65.20mm x 47.50mm)
Height - Seated (Max) 0.949" (24.10mm)
Win Source Part Number WS1307405-HS100 20R J
Ultra Librarian 3D Model Ultra Librarian HS100 20R J CAD Model

Description

20 Ohms ±5% 100W Wirewound Chassis Mount Resistor
