XF2B-4545-31A Real Image XF2B-4545-31A real image
Same model may have multiple batches, images only for reference.
XF2B-4545-31A Real Image XF2B-4545-31A real image
XF2B-4545-31A Real Image XF2B-4545-31A real image
Same model may have multiple batches, images only for reference.

XF2B-4545-31A

Part No XF2B-4545-31A
Manufacturer Omron
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN FPC 45POS 0.30MM R/A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Omron Electronics Inc-EMC Div
Packaging Reel
Status Obsolete
Flat Flex Type FPC
Mounting Style SMT, Right Angle
Connector/Contact Type Contacts, Top and Bottom
Number of Positions 45
Pitch 0.012" (0.30mm)
Termination Solder
FFC, FCB Thickness 0.20mm
Height Above Board 0.083" (2.10mm)
Locking Feature Rotary Lock, Backlock
Cable End Type Straight
Contact Material Copper Alloy
Contact Finish Gold
Dielectric Material Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material Liquid Crystal Polymer (LCP), Halogen Free
Voltage Rating 50V
Temperature Range - Operating -30°C ~ 85°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 0.2A
Contact Finish Thickness 5.90μin (0.150μm)
Housing Color Natural
Actuator Color Black
Mating Cycles 20
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 759732-XF2B-4545-31A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian XF2B-4545-31A CAD Model

Description

The XF2B-4545-31A is a high-quality, SMT right angle connector that features a rotary lock and backlock mechanism for added security. It is manufactured by Omron Electronics Inc-EMC Div.

  • Pitch: 0.012" (0.30mm)
  • Positions: 45
  • Cable/Wire Compatibility: FPC flat flex cables (0.20mm thick)
  • Voltage Rating: 50V
  • Contact Material: Copper Alloy
  • Contact Finish: Gold (5.90μin (0.150μm) thickness)
  • Height Above Board: 0.083" (2.10mm)
  • Actuator Material: Liquid Crystal Polymer (LCP), Halogen-free
  • Housing Color: Natural
  • Flammability Rating: UL94 V-0
  • Market Status: Popular
