The CAT4004VP2-GT3 is a high-performance, constant current LED driver designed by ON Semiconductor, a leader in energy-efficient innovations. This driver is specifically engineered to provide a simple and efficient solution for driving multiple LEDs in series, ensuring consistent brightness and extending LED life.

Key Features

• Output Current: The device offers up to four regulated current outputs, each capable of delivering 100mA to ensure uniform luminance for all connected LEDs.
• Low Dropout Voltage: With a low dropout voltage of 0.5V, the CAT4004VP2-GT3 maximizes power efficiency, which is crucial for battery-powered applications.
• Thermal Shutdown Protection: It includes a thermal shutdown protection mechanism that safeguards the device and the LEDs from overheating, enhancing system reliability.
• Voltage Range: The driver operates over a wide input voltage range from 2.5V to 5.5V, making it versatile for use in various applications.
• High Efficiency: The device is designed to be highly efficient, which reduces power consumption and heat generation.

Applications

The CAT4004VP2-GT3 is ideal for a wide array of applications where consistent LED brightness and efficiency are paramount. These include:

• Portable and battery-powered devices
• Backlighting for LCD displays
• Indicator and decorative LED lighting
• Automotive interior lighting
• General purpose LED illumination

Package and Quality

The device comes in a small, 16-lead TSSOP package, which is ideal for space-constrained applications. The CAT4004VP2-GT3 is RoHS compliant and is manufactured to meet the high-quality standards expected from ON Semiconductor, ensuring reliability and performance.

With its combination of features, the CAT4004VP2-GT3 from ON Semiconductor is an excellent choice for designers looking to enhance their LED driving capabilities while maintaining system efficiency and reliability.
