The CAT6219-285MV2T3 is a high-performance, fixed output voltage regulator from ON Semiconductor, designed to deliver a continuous output current of up to 500 mA. This low dropout (LDO) linear regulator offers a stable and precise 2.85V output voltage, making it an ideal power supply solution for various electronic applications that require a consistent and efficient power source.

Key Features

• Output Voltage: Fixed 2.85V with high accuracy.
• Output Current: Capable of delivering up to 500 mA of continuous current.
• Low Dropout: Offers a low dropout voltage, ensuring efficient operation even with a small input-to-output voltage differential.
• Thermal Protection: Integrated thermal shutdown feature protects the device from overheating during high current operation.
• Current Limiting: Built-in current limit functionality helps safeguard the device and the load from overcurrent conditions.
• Stable with Low ESR Capacitors: Compatible with ceramic capacitors, which have lower equivalent series resistance (ESR) for improved stability and performance.

Applications

The CAT6219-285MV2T3 is versatile and can be used in a wide range of applications, including but not limited to:

• Portable devices such as smartphones, tablets, and cameras.
• Wireless communication devices like Bluetooth headsets and GPS receivers.
• Battery-powered equipment where power efficiency is critical.
• Microcontroller or microprocessor power supplies.

Quality and Reliability

ON Semiconductor is known for its commitment to quality and reliability. The CAT6219-285MV2T3 is manufactured with this in mind, ensuring that it meets the stringent requirements of the industry. It is designed to perform consistently over a wide range of temperatures and operating conditions, making it a reliable choice for designers and engineers.

Package Information

The CAT6219-285MV2T3 comes in a compact, 5-pin TSOT-23 package, which is suitable for space-constrained applications. Its small size and low profile make it an excellent choice for portable and handheld devices where space is at a premium.
