ON Semiconductor CM1631-08DE - ESD Protection Device

The CM1631-08DE from ON Semiconductor is a robust ESD protection device designed to safeguard high-speed data lines from electrostatic discharge (ESD) and other transient voltage events. This component is particularly well-suited for applications that require reliable protection for sensitive electronics while maintaining signal integrity.

Key Features:

• ESD Protection: The CM1631-08DE offers excellent ESD protection exceeding IEC 61000-4-2 (Level 4) standards, ensuring devices are shielded against electrostatic discharges up to ±15kV (air discharge) and ±8kV (contact discharge).
• Low Capacitance: With a low input capacitance, this device is ideal for protecting high-speed data lines without compromising signal quality, making it suitable for USB 2.0, HDMI, and other high-speed interfaces.
• Low Leakage Current: It features a low leakage current that minimizes power consumption when the device is in standby mode, contributing to the overall energy efficiency of the system.
• Multiple Channel Protection: The CM1631-08DE provides protection for up to eight data lines, offering a compact and efficient solution for safeguarding multiple lines with a single device.
• Bi-Directional Protection: This component provides bi-directional protection, ensuring that both sides of the data line are protected from ESD strikes.

Applications:

The CM1631-08DE is versatile and can be used in a wide range of applications, including:

• Mobile Handsets
• Personal Computers
• Portable Electronics
• Digital Cameras
• MP3 Players
• Other USB Peripherals and Devices

Package and Quality:

ON Semiconductor's CM1631-08DE comes in a space-saving, lead-free, RoHS-compliant SOIC-16 package that is suitable for automated assembly processes. The device is manufactured to high-quality standards, ensuring reliability and performance in demanding electronic environments.

By integrating the CM1631-08DE into your design, you can enhance the durability and longevity of your electronic products, providing end-users with a more reliable and user-friendly experience.
