ON Semiconductor FDMC7696 DFN8 Product Overview

The FDMC7696 from ON Semiconductor is a high-performance, N-Channel PowerTrench® MOSFET designed for a wide range of applications requiring efficient power management and delivery. This semiconductor device is presented in a compact DFN8 (Dual Flat No-Lead 8-pin) package, making it an ideal choice for space-constrained environments where high power density is essential.

Key Features

• Low On-Resistance: The FDMC7696 boasts an exceptionally low on-resistance (R_DS(on)), which significantly reduces conduction losses and enhances overall efficiency in circuits.
• High Current Capability: Engineered to handle high current loads, this MOSFET can support applications that demand robust current handling without compromise.
• PowerTrench® Technology: ON Semiconductor's proprietary PowerTrench® process technology is employed to optimize the device for low gate charge and capacitance, leading to reduced switching losses and improved performance.
• Thermal Management: The DFN8 package is designed for excellent thermal performance, ensuring the device operates reliably under varying temperature conditions.
• RoHS Compliant: Adhering to environmental standards, the FDMC7696 is RoHS compliant, minimizing the environmental impact by avoiding the use of hazardous substances.

Applications

The versatility of the FDMC7696 allows it to be utilized in a diverse array of applications, including:

• DC/DC converters
• Power supply modules
• Battery management systems
• Motor drives and controls
• Computing and server power management
• Telecommunications equipment

Technical Specifications

The FDMC7696 operates with a continuous drain current (I_D) of 25 A, and a maximum drain-source voltage (V_DSS) of 30 V. Its low threshold voltage ensures that it can be driven by low-voltage logic signals, making it compatible with a wide range of control circuits and microcontrollers.

With its blend of high efficiency, reliability, and compact form factor, the FDMC7696 DFN8 from ON Semiconductor is a superior choice for designers looking to incorporate a high-quality MOSFET into their power management solutions.
