Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Obsolete(EOL)
Applications Analog
Number of Channels 1
Max On Resistance 150 Ohm
Single Supply Voltage (V+) 6 V to 18.5 V
Temperature Range - Operating -30°C to 75°C (TA)
Case / Package 30-PDIP
Win Source Part Number 127904-LC78212-E
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LC78212-E CAD Model

Description

The ON Semiconductor LC78212-E is an innovative analog function switch that is designed to deliver high-performance switching capabilities in a wide range of electronic applications. This versatile component is part of ON Semiconductor's esteemed lineup of semiconductor products, known for their reliability and cutting-edge technology.

The LC78212-E is an electronically controlled analog switch array with a silicon gate CMOS structure. It has an array of three SPDT (single-pole double-throw) switches and one SPST (single-pole single-throw) switch, which allows it to route analog signals under digital control. This enables the device to switch complex audio and video signals with minimal distortion and high signal integrity.

With an operating voltage range of 4.5V to 13.2V, the LC78212-E can be easily integrated into a variety of circuit designs. Its low crosstalk and high isolation between switches ensure that signal interference is minimized, making it particularly suitable for high-quality audio applications, such as mixers and signal selectors. The low on-resistance of the switch elements also contributes to maintaining signal quality by reducing power loss and preserving the integrity of the signal path.

The LC78212-E is equipped with a built-in shift register and latch circuit, which simplifies the control interface and reduces the number of control lines required. This feature makes it an excellent choice for designs where space and complexity are at a premium. Its serial data input can be used to control the switch states with a microcontroller or other digital logic, providing designers with flexibility and ease of use.

ON Semiconductor's commitment to quality ensures that the LC78212-E meets the stringent requirements for industrial and consumer electronic products. The device is available in a compact DIP (Dual In-line Package) or SOP (Small Outline Package), offering convenience for both through-hole and surface-mount applications.

In summary, the LC78212-E analog function switch from ON Semiconductor is a highly versatile and reliable solution for controlling analog signals in a digital environment. Its high performance and ease of integration make it an ideal choice for designers looking to create sophisticated electronic systems with superior signal handling capabilities.
