LM2931CDR2

Part No LM2931CDR2
Manufacturer ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description 100 mA, Adjustable Output, LDO Voltage Regulator with 60 V Load Dump Protection | IC REG LIN POS ADJ 100MA 8SOIC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Cut Tape (CT)
Status Obsolete
Output Type Adjustable
Voltage - Input (Maximum) 40V
Min/Fixed Output Voltage 2.7V
Maximum Output Voltage 29.5V
Maximum Dropout Voltage 0.6V at 100mA
Output Current 100mA
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number LM2931
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1198316-LM2931CDR2
Manufacturer Homepage www.onsemi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM2931CDR2 CAD Model

Description

ON Semiconductor LM2931CDR2 - Low Dropout Voltage Regulator

The ON Semiconductor LM2931CDR2 is a reliable and efficient low dropout voltage regulator designed to maintain stability and performance in automotive and battery-powered systems. This regulator is specifically engineered to withstand the rigors of automotive applications, with a robust design that ensures operation under extreme conditions.

Key Features

  • Output Voltage: The LM2931CDR2 provides a fixed output voltage of 5V, which is ideal for powering standard logic ICs and microcontrollers in automotive environments.
  • Low Dropout: With a low dropout voltage, this regulator can maintain output regulation with a minimal difference between the input and output voltages, making it highly efficient for systems with limited power.
  • High Current Output: It is capable of delivering up to 100 mA of output current, which is sufficient for a wide range of low-power applications.
  • Reverse Battery Protection: To safeguard against reverse polarity, which is a common issue in automotive power systems, the LM2931CDR2 includes built-in reverse battery protection.
  • Load Dump Protection: The device is designed to tolerate the load dump transients typical in automotive systems without succumbing to failure, thereby ensuring continuous operation.
  • Temperature Range: It operates over an extended temperature range from -40°C to +125°C, making it suitable for harsh environments.
  • Package: The regulator comes in a compact SOP-8 package, which is ideal for space-constrained applications.

Applications

The LM2931CDR2 is a versatile component that can be used in various applications, including:

  • Automotive electronics
  • Battery-powered devices
  • Portable instruments
  • Microcontroller power supply

Conclusion

With its robust design and comprehensive protection features, the ON Semiconductor LM2931CDR2 stands out as a dependable choice for designers seeking a low dropout voltage regulator for automotive and battery-powered applications. Its ability to perform under challenging conditions and provide stable power makes it an essential component for reliable electronic systems.
