MBRA120ET3G - ON Semiconductor Schottky Barrier Rectifier

The MBRA120ET3G from ON Semiconductor is a highly efficient, surface-mount Schottky Barrier Rectifier designed for applications that require low voltage drop and energy-saving high-frequency rectification. This component is a popular choice in the electronics industry due to its compact SMA package, which provides a space-saving solution on printed circuit boards.

Key Features:

• Voltage Rating: The MBRA120ET3G has a maximum repetitive peak reverse voltage of 20 volts, making it suitable for a wide range of low voltage applications.
• Current Capacity: It boasts a forward continuous current of 1 ampere, ensuring adequate current handling capabilities for many electronic circuits.
• Low Forward Voltage Drop: The device exhibits a low forward voltage drop, typically only 0.385 volts at 1 ampere, which contributes to its high efficiency and reduced power loss.
• Fast Switching Speed: With its Schottky barrier design, the MBRA120ET3G offers ultra-fast switching speeds, which is essential for high-frequency operations.
• Thermal Characteristics: It operates within a junction temperature range of -55°C to +125°C, ensuring reliability and stability across various environmental conditions.
• Package: The rectifier comes in an SMA package, which is not only space-efficient but also allows for easy installation and soldering onto PCBs.
• RoHS Compliant: The MBRA120ET3G meets the requirements of the RoHS directive, which restricts the use of certain hazardous substances in electronic equipment.

Applications:

This Schottky Barrier Rectifier is ideal for an array of applications, including:

• Power supply management
• DC-DC converters
• Free-wheeling diodes in converters and motor control circuits
• Polarity protection devices
• Low voltage, high-frequency inverters
• Lighting systems

The MBRA120ET3G is a testament to ON Semiconductor's commitment to providing high-quality, energy-efficient components for modern electronic devices. Its combination of low power loss, high efficiency, and fast switching makes it an excellent choice for designers looking to enhance the performance of their applications.
