MBRS130T3G - Schottky Power Rectifier
The MBRS130T3G is a robust and efficient Schottky Power Rectifier from ON Semiconductor, designed to provide low voltage, high-frequency rectification and freewheeling in power supplies and other power-switching applications. This state-of-the-art rectifier boasts a compact surface-mount package that ensures a small footprint on the PCB, making it ideal for space-constrained applications.
Key Features
- Low Forward Voltage Drop: The MBRS130T3G offers a low forward voltage drop, which enhances system efficiency by minimizing power losses during operation.
- High Surge Capacity: With its excellent surge handling capability, this rectifier can withstand high current peaks without performance degradation, ensuring reliability under stress conditions.
- Guardring for Overvoltage Protection: The inclusion of a guardring enhances the device's ability to handle overvoltage events, thus protecting the circuit from potential damage.
- Robust Thermal Performance: The MBRS130T3G is designed for optimal thermal performance, ensuring stability and longevity even under high temperature operating conditions.
- Low Power Loss/High Efficiency: Suitable for high efficiency, low power loss applications, this rectifier is a preferred choice for energy-sensitive designs.
Applications
The MBRS130T3G is versatile and can be used in a variety of applications, including:
- Switching power supply converters
- Free-wheeling diodes
- Reverse battery protection
- DC-to-DC converters
- Automotive applications
- Telecommunication systems
Technical Specifications
Parameter
Value
Package
SMB (Surface-Mount)
Peak Repetitive Reverse Voltage
30 V
Average Rectified Forward Current
1 A
Non-Repetitive Peak Surge Current
40 A
Operating Junction Temperature Range
-55°C to +150°C
With its combination of efficiency, reliability, and versatility, the MBRS130T3G from ON Semiconductor is an excellent choice for designers looking to improve their power management solutions.
