ON Semiconductor MC14011BFG Product Overview

The MC14011BFG from ON Semiconductor is a high-performance CMOS logic quad 2-input NAND gate integrated circuit. It is designed to deliver the functionality of the generic TTL counterpart but with the low power consumption and high noise immunity inherent to CMOS technology. This device is well-suited for a wide range of applications, including control systems, digital logic circuits, and various consumer electronics where efficient and reliable logic operations are required.

Key Features

• CMOS Technology: Utilizes advanced silicon-gate CMOS fabrication to achieve high-speed operation similar to LSTTL combined with the low power consumption of standard CMOS integrated circuits.
• Voltage Range: The device operates over a broad voltage range from 3V to 18V, making it versatile for various applications and compatible with TTL, CMOS, and PMOS logic levels.
• Quad 2-Input NAND Gates: Contains four independent NAND gates in a single package, providing compact and efficient use of space in circuit designs.
• High Noise Immunity: Features a noise immunity greater than 50% of the supply voltage (V<sub>DD), which enhances performance in electrically noisy environments.
• Low Power Consumption: Exhibits reduced power consumption, especially in the static condition, which is ideal for battery-powered or energy-sensitive applications.
• Output Drive Capability: Capable of driving up to 10 LSTTL loads, enabling the device to interface with various logic families.

Applications

• Automotive systems
• Control systems
• Data processing
• Consumer electronics
• Alarm systems
• Industrial electronics

The MC14011BFG is offered in a 14-lead SOIC package, providing a compact solution for printed circuit board layouts. Its operating temperature range of -55°C to +125°C ensures reliable performance across a wide spectrum of environmental conditions. With its robust design and ON Semiconductor's commitment to quality, the MC14011BFG stands as a solid choice for designers seeking a dependable NAND gate solution.
