Product Overview: MC74VHC1GT04DF - ON Semiconductor

The MC74VHC1GT04DF is a high-performance CMOS inverter integrated circuit from ON Semiconductor, designed to deliver the ultimate in speed and power efficiency for modern electronic applications. This device belongs to the 74VHC family, which is renowned for its low power consumption and high noise immunity equivalent to LS-TTL. The MC74VHC1GT04DF operates with a supply voltage range from 2V to 5.5V, making it versatile for use in a variety of systems.

This single gate inverter is fabricated with silicon gate CMOS technology, which ensures that it has superior switching characteristics and can operate at high speeds while maintaining low power dissipation. Its robust design allows it to tolerate high input surge currents, making it a reliable choice for critical applications.

The MC74VHC1GT04DF is equipped with input and output interface capability to systems at 5V, which is essential for mixed-voltage applications. It boasts a high drive capability, with outputs capable of driving 10 LS-TTL loads. The high impedance of the CMOS input structure ensures low input currents, further optimizing the device for low-power operations.

ON Semiconductor has designed the MC74VHC1GT04DF with a propagation delay time that is significantly reduced, thus enhancing the performance of the overall system in which it is used. This makes it an excellent choice for high-speed logic applications and situations where power efficiency is a key concern.

The MC74VHC1GT04DF comes in a small footprint package, the SC-88A, which is ideal for space-constrained applications. It is also available in a variety of other package types to suit different design needs. The device is fully characterized for hot-insertion, which means it can be safely added to live systems without risk of damage.

With its combination of high-speed operation, low power consumption, and robust construction, the MC74VHC1GT04DF from ON Semiconductor is a perfect choice for designers looking to optimize their digital logic applications. Whether it's used in consumer electronics, automotive systems, or industrial controls, this device promises reliable performance and energy efficiency.
