ON Semiconductor MC74VHCT50ADR2G Description

The MC74VHCT50ADR2G from ON Semiconductor is a versatile, high-performance CMOS logic level shifter/translator IC designed to meet the needs of modern electronics. This advanced device is capable of converting logic-level signals to be compatible with different voltage domains, making it an essential component for interfacing between various digital systems operating at distinct voltage levels.

Constructed with silicon gate CMOS technology, the MC74VHCT50ADR2G offers a robust solution for logic level translation without compromising on speed or power efficiency. The device is characterized by its low power consumption and high noise immunity, typical of CMOS devices, while also providing the added benefit of high-speed performance similar to LSTTL outputs.

This non-inverting logic level shifter comes in a compact SOIC-14 package, which is ideal for space-constrained applications. It operates over a broad voltage range from 4.5V to 5.5V, ensuring compatibility with 5V TTL logic, while its outputs can interface with both 3.3V and 5V logic levels. This makes the MC74VHCT50ADR2G a perfect choice for mixed-voltage systems and for bridging devices that operate at different logic levels.

Featuring a high drive capability, the MC74VHCT50ADR2G can drive up to 10 LSTTL loads, ensuring reliable performance in a wide range of applications, including computing, data communication, and consumer electronics. Its fast propagation delay and transition times further enhance its suitability for high-speed signal processing tasks.

For protection and reliability, the MC74VHCT50ADR2G incorporates input hysteresis, which allows for improved noise margins and increased stability. It also provides latch-up performance that exceeds 250mA, conforming to the JEDEC standard JESD 17, which guarantees resilience against latch-up phenomena.

In summary, the MC74VHCT50ADR2G from ON Semiconductor is a high-quality, flexible solution for systems requiring logic level translation. With its high-speed operation, low power consumption, and compatibility with multiple logic levels, it stands out as an excellent choice for designers looking to create seamless interfaces between different digital components.
