ON Semiconductor NCP1034DR2G Overview

The ON Semiconductor NCP1034DR2G is a high-performance, low-standby-power, high-voltage switcher that is designed to meet the stringent requirements of a wide range of electrical and electronic applications. This versatile component is particularly well-suited for use in power supplies, where it can help to improve efficiency, reliability, and power density.

Key Features

• High Voltage Capability: With an integrated high-voltage startup FET, the NCP1034DR2G can handle up to 100V, making it ideal for handling wide input voltage ranges common in industrial and consumer electronic products.
• Adjustable Output Voltage: The device allows for a flexible output voltage setting, which enables designers to tailor the output to the specific needs of their application.
• Frequency Jittering: Frequency jittering reduces EMI emissions and can help in meeting various regulatory standards without the need for additional filtering components.
• Current Mode Control: This feature provides fast transient response and cycle-by-cycle current limiting, enhancing the overall safety and performance of the power supply.
• Overvoltage, Overcurrent, and Overtemperature Protections: The NCP1034DR2G is equipped with multiple protection features that safeguard the device and the system it powers against a range of potential faults.

Applications

The versatility of the NCP1034DR2G makes it suitable for a variety of applications including:

• AC-DC adapters for consumer electronics
• Offline battery chargers
• Auxiliary power supplies for white goods
• Standby and auxiliary power supplies

Package and Quality

Housed in a compact 7-pin D2PAK package, the NCP1034DR2G is designed for minimal footprint and ease of integration into various circuit designs. ON Semiconductor’s commitment to quality ensures that this high-voltage switcher is reliable and performs consistently, making it a trusted choice for engineers and designers looking for a robust power solution.

With its combination of high-voltage capability, efficiency, and protection features, the NCP1034DR2G from ON Semiconductor is an excellent choice for anyone seeking a high-performance power switching solution.
