ON Semiconductor's NCP716MTG50TBG: A Compact, High-Performance LDO Regulator

The NCP716MTG50TBG from ON Semiconductor is a high-quality, low-dropout (LDO) voltage regulator, designed to deliver a stable and precise voltage supply. This LDO is particularly well-suited for portable devices, where energy efficiency and space constraints are key considerations.

Key Features

• Output Voltage: The device provides a fixed output voltage of 5.0V, which is ideal for powering a wide range of standard digital and analog circuits.
• High Accuracy: With an output voltage accuracy of ±2%, the NCP716 ensures reliable operation of sensitive electronic components requiring stable power inputs.
• Low Dropout: The low dropout voltage of just 145 mV at 80 mA load allows for efficient operation, even when the supply voltage is close to the output voltage, thus conserving battery life in portable applications.
• Current Capacity: It can deliver up to 150 mA of continuous output current, which is sufficient for a variety of small-scale electronic devices.
• Thermal Protection: The built-in thermal shutdown feature protects the device from damage due to overheating, enhancing the product's reliability and lifespan.
• Power Supply Rejection Ratio (PSRR): With an excellent PSRR of 75 dB at 1 kHz, the NCP716 provides stable output despite fluctuations in the input voltage, which is crucial for high-performance applications.

Compact Design

The NCP716MTG50TBG is available in a space-saving 5-pin TSOP-5 package, making it an excellent choice for space-constrained applications. Its small footprint allows for high-density PCB layouts, which is essential for modern, compact electronic products.

Applications

This LDO regulator is versatile and can be used in a variety of applications, including:

• Portable and battery-powered devices
• Microcontroller power supplies
• Wireless communication systems
• Personal electronics (e.g., cameras, MP3 players)

With its combination of high performance, accuracy, and compact design, the NCP716MTG50TBG from ON Semiconductor is an exceptional choice for designers looking for a reliable LDO voltage regulator for their next project.
