NTH4L060N090SC1

Part No NTH4L060N090SC1
Manufacturer ON Semiconductor
Catalog FETs - Single
Description SILICON CARBIDE MOSFET, NCHANNEL
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number WS1203037-NTH4L060N090SC1
Manufacturer onsemi
Category Discrete Semiconductor Products- Transistors FETs, MOSFETs -Single FETs, MOSFETs
Package Tube
Product Status Active
FET Type N-Channel
Technology SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss) 900 V
Operating Temperature -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Supplier Device Package TO-247-4L

Description

ON Semiconductor NTH4L060N090SC1 Power MOSFET

The ON Semiconductor NTH4L060N090SC1 is a high-performance, N-channel Power MOSFET designed to meet the rigorous demands of today's power electronic applications. This device is a part of ON Semiconductor's portfolio of energy-efficient power management solutions, offering a combination of low on-resistance and high switching speed, making it ideal for a wide range of applications including power supplies, motor control, and power conversion systems.

Key Features

  • Low On-Resistance: The NTH4L060N090SC1 boasts an exceptionally low on-resistance, which translates to reduced conduction losses and improved overall efficiency in power conversion applications.
  • High Switching Speed: With its fast switching capabilities, this MOSFET minimizes switching losses and is well-suited for high-frequency operation.
  • High Current Capability: This device is capable of handling high continuous drain currents, making it suitable for high power applications.
  • Robust Thermal Performance: The MOSFET's excellent thermal characteristics ensure reliable operation even under high temperature conditions.
  • Advanced Technology: Manufactured with ON Semiconductor's advanced technology, the NTH4L060N090SC1 provides superior performance and reliability.

Applications

  • DC/DC Converters
  • AC/DC Power Supplies
  • Motor Drives
  • Power Inverters
  • Electric Vehicles
  • Industrial Power Management

The NTH4L060N090SC1 from ON Semiconductor is a testament to the company's commitment to providing power solutions that enhance energy efficiency and reduce environmental impact. Its robust design ensures long-term reliability, while its energy-efficient operation helps to minimize power losses in a variety of electronic systems. Whether you're designing a power supply for industrial equipment or a motor drive for an electric vehicle, the NTH4L060N090SC1 offers the performance and durability needed to create a high-quality, efficient product.

For detailed specifications and application notes, designers and engineers are advised to consult the official ON Semiconductor datasheets and product guides.
