The ECHU1H101GX5 is a film capacitor manufactured by Panasonic. This capacitor belongs to the EC Series, known for its high reliability and excellent electrical characteristics. It is designed for a wide range of applications requiring stable capacitance and low losses.

Applications:

• Power supplies
• Inverters
• Audio equipment
• Lighting ballasts
• General-purpose electronic circuits

Features:

• Capacitance: 100pF
• Voltage Rating: 50V DC
• Tolerance: ±2%
• Dielectric Material: PPS (Polyphenylene Sulfide) Film
• Operating Temperature Range: -40°C to +105°C
• RoHS Compliant: Yes
• Lead Spacing: 5mm
• Flame Retardant Epoxy Resin Coating: Provides excellent moisture resistance and insulation.
• Self-Healing Properties: Allows the capacitor to recover from minor over-voltage events, enhancing its reliability.

Benefits:

• High Stability: The PPS film dielectric ensures excellent capacitance stability over a wide temperature range.
• Low Losses: Provides efficient performance in high-frequency applications.
• Long Life: Designed for long-term reliability in demanding environments.
• Compact Size: Allows for dense circuit board designs.
• Safety: Flame retardant coating enhances safety.

Additional Details:

The ECHU1H101GX5 is constructed with a metallized PPS film, offering a stable capacitance value and low dissipation factor. Its compact size makes it suitable for space-constrained applications. The capacitor's excellent electrical characteristics and high reliability make it a preferred choice for various electronic devices.

This capacitor is suitable for filtering, coupling, decoupling, and timing circuits. The 2% tolerance ensures accurate performance in sensitive applications.
