PE42421SCAA-Z

Name: PE42421SCAA-Z
Brand: Peregrine Semiconductor
SKU: 503722
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PE42421SCAA-Z
Manufacturer	Peregrine Semiconductor
Catalog	RF Switches
Description	RF Switch SPDT 10MHz to 3GHz 19dB 6-Pin SC-70 T/R / IC RF SWITCH SPDT 50 OHM SC70-6
Datasheet	PE42421SCAA-Z Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	RF/IF and RFID
Manufacturer	Peregrine Semiconductor
Packaging	Reel - TR
Status	Active
Frequency - Lower	10MHz
Frequency - Upper	3GHz
Isolation @ Frequency	20dB @ 2GHz (typ)
Insertion Loss @ Frequency	0.5dB @ 2GHz
IIP3	55dBm (typ)
Topology	Reflective
Circuit	SPDT
P1dB	30.5dBm (typ) IP1dB
Features	Single/Dual Line Control
Impedance	50 Ohm
Temperature Range - Operating	-40°C to 85°C
Supply Voltage - Operating	1.8 V to 3.3 V
RF Type	General Purpose
Case / Package	SC-70-6
Win Source Part Number	1087284-PE42421SCAA-Z
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	PE42421
Introduction Date	September 27, 2011
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian PE42421SCAA-Z CAD Model

Alternative Products

Description

The Peregrine Semiconductor PE42421SCAA-Z is a reflective, SPDT circuit that operates from 10 MHz to 3 GHz.

Operating Frequency: 10 MHz to 3 GHz
Isolation @ 2 GHz: 20 dB (typ)
Insertion Loss @ 2 GHz: 0.5 dB
IIP3: 55 dBm (typ)
P1dB: 30.5 dBm (typ) IP1dB
Application: RF/IF and RFID
Package: SC-70-6
Status: active
Popularity: high
Supply and Demand Status: balance
Application: general-purpose RF applications
