TOP224YN Power Integrations TOP224YN Real Image TOP224YN real image TOP224YN real image 2
Same model may have multiple batches, images only for reference.
TOP224YN Power Integrations TOP224YN Real Image TOP224YN real image TOP224YN real image 2
TOP224YN Power Integrations TOP224YN Real Image TOP224YN real image TOP224YN real image 2
Same model may have multiple batches, images only for reference.

TOP224YN

Part No TOP224YN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT PWM OCP HV TO220
Datasheet
TOP224YN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Boost, Buck, Flyback, Forward
Duty Cycle 67%
Frequency - Switching 100kHz
Power (Watts) 75W
Fault Protection Current Limiting, Over Temperature
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package TO-220-3
Mounting Through Hole
Win Source Part Number 033355-TOP224YN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TOP224
ECCN EAR99
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian TOP224YN CAD Model

Description

The Power Integrations TOP224YN is an integrated circuit manufactured by Power Integrations.

  • Power: 75W
  • Output Isolation: Isolated
  • Internal Switch: Internal switch
  • Voltage Breakdown: 700V
  • Topology: Boost, buck, flyback, forward
  • Duty Cycle: 67%
  • Frequency of Switching: 100kHz
  • Fault Protection: Current limiting and over-temperature protection
  • Case/Package: TO-220-3
  • Mounting: Through hole
  • Control Operating Temperature Range: -40°C to 150°C
  • Product Status: Not for new designs
  • Estimated EOL date: 2019
  • Description: The integrated circuit is suitable for use in various electronic devices that require this specific integrated circuit.
