H5004NL Real Image H5004NL real image18037 H5004NL real image18038
Same model may have multiple batches, images only for reference.
H5004NL Real Image H5004NL real image18037 H5004NL real image18038
H5004NL Real Image H5004NL real image18037 H5004NL real image18038
Same model may have multiple batches, images only for reference.

H5004NL

Part No H5004NL
Manufacturer Pulse
Catalog Pulse Transformers
Description RoHS peak reflow temperature rating 245 C | MODULE SINGLE GIGABIT LAN 24SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Pulse Electronics Network
Packaging Tube
Transformer Type LAN 1000 Base-T
Mounting Style SMD
Parts Dimension 0.690" L x 0.480" W (17.53mm x 12.20mm)
Height - Seated (Maximum) 0.227" (5.76mm)
Temperature Range - Operating 0°C ~ 70°C
Weight 0.06 oz (1.71g)
Manufacturer Pack Quantity 25
MSL Level 4 (72 Hours)
Win Source Part Number 1178286-H5004NL
Manufacturer Homepage www.pulseeng.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian H5004NL CAD Model

Description

The Pulse Electronics Network LAN 1000 Base-T transformer is an SMD transformer that is ideal for use in a wide range of electronic devices.

  • Weight: With a weight of just 0.06 oz (1.71g)
  • Height: and a height of 0.227" (5.76mm), this transformer is compact and easy to install.
  • Temperature Range: It has a temperature range of 0°C to 70°C, making it suitable for use in a variety of environments.
  • Series: The transformer is part of the Pulse Electronics Network series
  • Status: and has a limited supply and demand status.
  • Packaging: It comes in a tube packaging
  • Manufacturer Pack Quantity: and has a manufacturer pack quantity of 25.
