The Ramtron FM24C16-G is a 16-Kilobit (2K x 8) Serial (I2C) F-RAM (Ferroelectric Random Access Memory). This non-volatile memory provides fast read and write times, high endurance, and low power consumption, making it suitable for a wide range of applications where frequent data logging or storage is required.

Applications

• Data Logging: Used in applications requiring frequent and reliable data storage, such as sensor data logging.
• Metering: Suitable for storing meter readings in smart meters and other metering devices.
• Industrial Control: Employed in industrial control systems for storing configuration parameters and operational data.
• Medical Devices: Used in medical equipment for storing patient data and device settings.
• Automotive Electronics: Can be found in automotive systems for storing diagnostic data and vehicle settings.

Features

• 16-Kilobit (2K x 8) F-RAM: Provides non-volatile memory storage.
• High Endurance: Offers virtually unlimited read/write cycles.
• Fast Write Capability: Supports fast write operations without delays.
• Low Power Consumption: Reduces overall system power consumption.
• I2C Serial Interface: Uses a standard I2C interface for easy communication with microcontrollers.

Benefits

• Data Retention: Retains data for extended periods even without power.
• High Reliability: Provides reliable data storage in harsh environments.
• Simplified Design: Simplifies system design due to the I2C interface.
• Reduced Power: Low power consumption extends battery life in portable devices.
• Fast Operation: Enables quick and efficient data access.

Technical Specifications

The FM24C16-G operates from a supply voltage range of 2.7V to 3.6V. It communicates via the standard I2C serial interface with clock frequencies up to 1 MHz. The device offers extremely high endurance, capable of withstanding 10^14 read/write cycles. It is available in a standard 8-pin package. Refer to the Ramtron datasheet for detailed electrical characteristics, timing diagrams, and package dimensions.
