Products specifications

Manufacturer RF Micro Devices
Win Source Part Number 1242568-RF2908
Manufacturer Homepage www.rfmd.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2908 CAD Model

Description

The RF2908 is a highly integrated Front-End Module (FEM) designed for WLAN applications, manufactured by RF Micro Devices (now Qorvo). This module typically integrates a power amplifier (PA), a low noise amplifier (LNA), and a transmit/receive (T/R) switch into a single compact package. It's designed to simplify the design and improve the performance of WLAN front-end circuitry.

Applications:

  • WLAN (Wireless Local Area Network) devices
  • Wi-Fi routers
  • Access points
  • Wireless adapters
  • Mobile devices (smartphones, tablets)

Features:

  • Integrated PA, LNA, and T/R switch: Reduces component count and board space.
  • High output power: Enables extended wireless range.
  • Low noise figure: Improves receiver sensitivity.
  • Compact package: Facilitates miniaturization of wireless devices.
  • Optimized for WLAN standards: Complies with IEEE 802.11 standards.

Benefits:

  • Simplified design: Reduces design complexity and time-to-market.
  • Improved performance: Enhances wireless range and signal quality.
  • Reduced size and cost: Minimizes component count and board area.
  • Increased reliability: Integration reduces the number of discrete components that could fail.

Additional Details:

The RF2908 is typically optimized for the 2.4 GHz frequency band used in WLAN applications. It often includes features like power control and harmonic filtering. The integration of multiple functions into a single module reduces the need for external components, simplifying the design process and reducing the overall size of the wireless device. Careful impedance matching and layout are still crucial for optimal performance. The RF2908 is typically used in applications where space constraints and performance are critical considerations, such as in mobile devices and compact wireless routers.
