PX1004 RF Monolithics, Inc
Same model may have multiple batches, images only for reference.

PX1004

Part No PX1004
Manufacturer RF Monolithics, Inc
Catalog SAW Filters
Description FILTER,PX,82.200 MHZ
Datasheet
PX1004 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - SAW Filters
Mfr RF Monolithics, Inc
Package Tape & Reel (TR)Tape & Reel (TR)Bag
Product Status Active
Frequency - Center 82.2MHz
Bandwidth 50kHz
Insertion Loss 3dB
Applications Cellular, TDMA, IF
Mounting Type Surface Mount
Package / Case 12-SMD, No Lead
Height (Max) 0.079" (2.00mm)
Size / Dimension 0.524" L x 0.256" W (13.31mm x 6.50mm)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0060
Win Source Part Number 658274-PX1004
Ultra Librarian 3D Model Ultra Librarian PX1004 CAD Model

Description

The PX1004 is a surface mount SAW filter from RF Monolithics, Inc. It is designed for cellular and TDMA applications, as well as IF filtering.

  • Frequency Center: 82.2MHz
  • Bandwidth: 50kHz
  • Insertion Loss: 3dB
  • Height: 0.079" (2.00mm)
  • Package: 12-SMD, no lead package
  • Standard Package: 3,000 pcs
