PF2205-5RF1 Real Image PF2205-5RF1 Real Image
Same model may have multiple batches, images only for reference.
PF2205-5RF1 Real Image PF2205-5RF1 Real Image
PF2205-5RF1 Real Image PF2205-5RF1 Real Image
Same model may have multiple batches, images only for reference.

PF2205-5RF1

Part No PF2205-5RF1
Manufacturer Riedon
Catalog Through Hole Resistors
Description RES 5 OHM 50W 1% TO220 / Power Thin Film Resistor TO-220
Datasheet
PF2205-5RF1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Resistors
Manufacturer Riedon
Series PF2200
Packaging Tube
Resistance (Ohms) 5
Tolerance ±1%
Power (Watts) 50W
Composition Thin Film
Temperature Coefficient ±100ppm/°C
Operating Temperature Range -55°C ~ 155°C
Package TO-220-2
Manufacturer Package TO-220
Dimension 0.417" L x 0.177" W (10.60mm x 4.50mm)
Height - Seated (Maximum) 0.591" (15.00mm)
Number of Terminations 2
Win Source Part Number 791724-PF2205-5RF1
Popularity Medium
Supply and Demand Status Limited
Introduction Date August 11, 2017
ECCN EAR99
Estimated EOL Date 2035
Ultra Librarian 3D Model Ultra Librarian PF2205-5RF1 CAD Model

Description

The PF2205-5RF1 is a through-hole resistor that belongs to the PF2200 series of resistors from PF2200.

  • Series: PF2200
  • Power Rating: 50W
  • Resistance: 5 Ohms
  • Package: Tube
  • Length: 0.417 inches
  • Width: 0.177 inches
  • Height: 0.591 inches
  • Tolerance: ±1%
  • Temperature Coefficient: ±100ppm/°C
  • Package/Case: TO-220-2
  • Supplier Device Package: TO-220
  • Operating Temperature Range: -55°C to 155°C
